Features
- Compact design
- Overheat protection
- LED display with PID control of 0.1°C resolution
- Self-diagnosed abnormality function
- Delayed resume compressor protection
- Jetstream forced-flow circulation
- Built on wheels for maximum mobility
Specifications
Water Cooling Circulator Specifications
| Cat. No. | WCC-100 | WCC-101 |
|---|---|---|
| Display | LED Display | |
| Temperature control range | 0oC to +100oC | |
| Temperature stability | ± 0.5oC at 20oC | |
| Temperature accuracy | ± 0.5oC at 20oC | |
| Controller | PID control, PT100 sensor | |
| Setting / display resolution | ± 0.1°C | |
| Cooling capacity (Medium Ethanol) | 1900 BTU/h @ 0°C | |
| Pump capacity flow rate (L/min) | 5.5 L/min | |
| Hydraulic head | 2.5 meter | |
| Pump capacity flow pressure (bar) | 0.19 bar | |
| Pump connections | 1/4" silicone tubing | |
| Barbed fittings diameter (inner dia. / mm) | 6.35 mm or 1/4" | |
| Bath capacity | 10 L | |
| Refrigerant | CFC free refrigerants-R134a | |
| Operating temperature | +20°C~+40°C | |
| Operating humidity | Max.80% | |
| Rated voltage | 110V; 60Hz, 14.5A | 220V; 50Hz, 8A |
| Chamber material | 304 stainless steel | |
| Bath inner dimension | (W x L x H) 9.25"x11.61"x5.90" (235x295x150 mm) | |
| External material | Powder coating | |
| Compressor | 1/4 HP | |
| Dimension | (W x L x H) 13.39"x22.04"x26.38" (340x560x670 mm) | |
| Weight | Approx. 110.2 lb (50 kg) | |
| Safety device | ■ Self-diagnosed abnormality display ■ Electronic overheating thermal fuse protection in increments of 0.1oC ■ Delayed resume compressor protection |
|
| Circulation volume | Cycles up to 5.5 L/min cooling system with delayed resume protection after power outage | |
| Circulation type | Jet stream flow forced circulation, can be accessed through the outer loop | |
| Power | 1000W | |
